How deep can a cat 304 dig?
Dimensions – Long Stick
| Dig Depth | 135 in 3430 mm |
|---|---|
| Maximum Reach | 220 in 5590 mm |
| Vertical Wall | 101 in 2560 mm |
| O/A Shipping Height | 98 in 2500 mm |
| Boom Swing – Right | 29 in 735 mm |
How much does a CAT 304c weight?
10844 lb
Specification
| Engine | |
|---|---|
| Displacement | 153 cu in 2505 L |
| Number Of Cylinders | 4 |
| Operational | |
| Operating Weight | 10844 lb 4920 kg |
How much does a Yanmar vio35 weight?
8,214 lbs
The YANMAR ViO35-6A is the most productive digging, lifting, do-anything excavator you can buy….The most advanced excavator we’ve ever made.
| Weight (cab) | 8,214 lbs |
|---|---|
| Horsepower | 24.4 HP |
| Digging Depth | 11’3″ |
What does a John Deere 35g excavator weigh?
8,135 lb.
Digging Depth: 3.06 m (10 ft. 0 in.) Operating Weight: 3690 kg (8,135 lb.)
How much can a cat 305 lift?
Lift Capacities at Ground Level – Lift Point Radius: 4000 mm (13’1”)
| Blade Down – Side | 1411 lb 640 kg |
|---|---|
| Blade Down – Front | 2778 lb 1260 kg |
| Blade Up – Side | 1257 lb 570 kg |
| Blade Up – Front | 1676 lb 760 kg |
How deep will a Yanmar 35 dig?
Yanmar Vio 35 Specs
| Boom/Stick Option (HEX) 1 | ||
|---|---|---|
| A. SHIPPING LENGTH OF UNIT | 15.2 ft in | 4640 mm |
| K. MAX REACH ALONG GROUND | 17.1 ft in | 5220 mm |
| L. MAX VERTICAL WALL DIGGING DEPTH | 9.4 ft in | 2850 mm |
| M. MAX DIGGING DEPTH | 10.8 ft in | 3300 mm |
